Lefoo High Accuracy Low Range Differential Pressure Transmitter LFM53

Name: High Accuracy Low Range Differential Pressure Transmitter LFM53
Brand: LEFOO INDUSTRIAL CO.,LTD.
Rating: 4.8 (50 reviews)

LEFOO LFM53 differential pressure transmitter adopts a thermal micro-pressure core, and uses the micro-flow path integrated with the sensor chip to detect the air pressure by detecting the change of the flow rate of the thermal airflow. It has the characteristics of strong overload capacity, strong anti-electromagnetic interference ability, wide measurement range, and multi-signal output. Widely used in the detection of air or neutral gases, such as HVAC, process control, environmental control, clean room, or other detection systems that require differential pressure.

Features

* Imported thermal micro-pressure core body, sensitive to pressure

* Range as low as ±25Pa

* Overload pressure up to 2Bar

* Accuracy up to 0.5%F.S., strong stability, good repeatability

* Easy installation, insensitive to installation position

* Strong anti-interference ability, optional isolated output

Get a Quote PDF Download

Transmitter

Pump

Specification
Features
Applications

Specification of High Accuracy Low Range Differential Pressure Transmitter LFM53

Technical parameter

LEFOO High Accuracy Low Range Differential Pressure Transmitter LFM53
Medium	air or neutral gas
Pressure Range	±25Pa, ±50Pa, ±100Pa
Overpressure capacity	2Bar
Accuracy	±25Pa, ±1Pa
	±50Pa, ±1%F.S.
	±100Pa, ±0.5%F.S.
Operating temperature	-20℃~70℃
Storage temperature	-40℃~80℃
Temperature drift	0.03%F.S./℃
Protection Level	IP65
Electrical connection	Four-wired	Six-wired
Output signal	RS-485	4~20mA/ 0~10VDC
Power supply	9~30 VDC/24VAC±20%	12~30 VDC/24VAC±20%
Pressure interface	Metal barbed interface,φ6.2mm
Communication	RS-485 Standard interface, Modbus RTU protocol
Certification	ROHS certification，EU CE certification
Electromagnetic compatibility	EN 61326-1

Dimension

LEFOO Air Differential Pressure Transducer LFM51

Selection Guide

Code and Description					Remark
LFM53	High Accuracy Low Range Differential Pressure Transmitter				Model
	1	-25～25pa			Range
	2	-50～50pa
	3	-100～100pa
		N	No display		Display
		O	With display
			A	4~20mA +0~10VDC( Simultaneous output)	Output type
			E	RS-485 communication
			E1	RS-485 communication（with isolation）

LFM53	1	O	E		Selection example

Features of High Accuracy Low Range Differential Pressure Transmitter LFM53

Imported thermal micro-pressure core body, sensitive to pressure
Range as low as ±25Pa
Overload pressure up to 2Bar
Accuracy up to 0.5%F.S., strong stability, good repeatability
Easy installation, insensitive to installation position
Strong anti-interference ability, optional isolated output

Applications of High Accuracy Low Range Differential Pressure Transmitter LFM53

Air and Neutral gas pressure measuring

Noise environmental protection project bellows
