Our 230V AC Diaphragm Booster Pump, perfect for a variety of applications including
sparkling water cooler carbonation systems, water coolers, water fountains, water
purifiers, soda machines, misting systems, vending machines, hydrogen water
machines, floor scrubbers, cleaning machines, carpet cleaning machines and so on.
Safety features including thermal protection, overcurrent protection, and
overvoltage protection.
Certifications from NSF, UL, EU FOOD (European Food Grade), FDA, and CE.
An odorless design, making it suitable for use with potable water.
Direct power connection without the need for an adapter, saving space
and reducing overall weight.
Low noise levels and exceptional long-term stability.
| Parameters of 230VAC RO Diaphragm Booster Pump | |||||||||||||
| Connection | 3/8"NPT, 3/8NPT'O', 1/4" Top Female quick connector, 1/4" Side female quick connector, 5/16" Side female quick connector, 1/4" Male quick connector | ||||||||||||
 | |||||||||||||
| Model | LFP6050W | LFP6075W | LFP6100W | LFP6150W | LFP6200W | LFP6300W | LFP6400W | LFP6500W | LFP6600W | ||||
| Voltage | 230VAC | ||||||||||||
| Inlet Pressure | 0.2MPa | ||||||||||||
| Boost Pressure | 0.5Mpa | 0.5Mpa | 0.7Mpa | 0.5Mpa | 0.7Mpa | ||||||||
| Work Current | ≤0.13A | ≤0.14A | ≤0.16A | ≤0.17A | ≤0.18A | ≤0.24A | ≤0.3A | ≤0.34A | ≤0.39A | ≤0.39A | ≤0.43A | ||
| Work Flow | ≥600ml/min | ≥750ml/min | ≥980ml/min | ≥1500ml/min | ≥1900ml/min | ≥2700ml/min | ≥2950ml/min | ≥3250ml/min | ≥2800ml/min | ≥3600ml/min | ≥3200ml/min | ||
| Open Flow | ≥1600ml/min | ≥1800ml/min | ≥2000ml/min | ≥2200ml/min | ≥2500ml/min | ≥3500ml/min | ≥4000ml/min | ≥4800ml/min | ≥5500ml/min | ||||
| Bypass Pressure | 0.8~1.05Mpa | ||||||||||||
| Max Current | ≤0.24A | ≤0.24A | ≤0.28A | ≤0.28A | ≤0.3A | ≤0.4A | ≤0.45A | ≤0.53A | ≤0.57A | ||||
| Certifications | NSF, CE, ROHS, REACH, EU Food Grade | ||||||||||||
Compliant with Rohs, CE, CQC certification
Robust Structure featured with Food Grade Parts
Easy install, low noise, and outstanding vibration control
Whole process quality control in electrical, sealing, and water production.
I. Robust Power for High-Efficiency Operation
Powered by 230V AC voltage, the booster pump provides ample power, ensuring efficient operation under various working conditions. Whether it's handling high flow rates or enduring prolonged continuous use, the 230V pump handles them all effortlessly, serving as a reliable power source for beverage equipment.
II. Comprehensive Safety Features for Enhanced Security
Similar to the 115V version, the 230V booster pump also boasts thermal protection, overcurrent protection, and overvoltage protection mechanisms. These safety features effectively prevent equipment damage caused by abnormal situations, offering users even greater peace of mind.
III. International Certifications for Premium Quality
Bearing certifications from NSF, UL, FDA, and CE, the 230V booster pump meets the highest international quality standards. This diaphragm booster pump material selection, manufacturing processes, and performance are all rigorously tested to ensure compliance with the strictest requirements.
IV. Food-Grade Materials for Safe and Healthy Drinking Water
Water-contacting components are crafted from food-grade materials, ensuring the purity and safety of the water. This feature makes the 230V booster pump an ideal fit for various beverage preparation devices, delivering consumers healthy and safe drinking experiences.
V. Low-Noise Operation for Enhanced Environmental Comfort
Equipped with advanced noise reduction technology, the 230V booster pump operates quietly, creating a more serene work environment. This characteristic is especially beneficial in settings requiring quiet atmospheres, such as libraries and cafes.
Wide Range of Applications
Vending Machines: Ensuring efficient and stable beverage dispensing.
Hydrogen Water Machines: Offering a new option for healthy drinking water.
Floor Scrubbers, Cleaning Machines, and Carpet Cleaners: Demonstrating superior performance in the cleaning industry, enhancing cleaning efficiency and quality.
RO water purifier, Aeroponics and hydroponics， RO system, pressure adding pump
Water Treatment/RO
Carbonation Systems
Beverage/Coffee Systems
Water Vending, Dispensing
Hydroponics/Aeroponics
Misting Systems
Surface Sanitation
Humidification
HVAC Coil Cleaning
Medical Lab Water
Autoclave Systems
Endoscope Reprocessing/Chemical Boost
Dialysis Chemical Injection
Methanol & Water Injection
Sparkling Water Machine
Commercial Sparkling Water Machine
Commercial Carbonated Water Machine
Carbonation Systems
Commercial Water Dispenser
Water Dispensers
Soda Machine
RO Purifier
RO Water Dispenser
Water Coolers
Misting System
Teeth Cleaning Industry
