Lefoo Submersible Liquid Level Transmitter LFT3000

LEFOO LFT3000 submersible liquid level transmitter uses a high-performance pressure sensor as the measuring element to accurately measure the liquid level depth with submersible pressure sensors, and convert it into a standard output signal through a special signal conditioning circuit to establish a linear correspondence between the output signal and the liquid depth. Accurate measurement of depth. The product has high precision, small volume and convenient use. It can measure the liquid level height from the end of the transmitter to the liquid surface when it is directly put into the liquid. It is suitable for water level or liquid level measurement and control in the fields of petroleum, chemical industry, power plant, urban water supply, and hydrological exploration.



LEFOO Pressure Level Transmitter LFT3000 Features

* Adopt oil-filled diffusion silicon core with high precision and high overload capacity

* Excellent corrosion and wear resistance

* Built-in temperature compensation, support Modbus-485 communication protocol (intelligent type)

* The bottom stainless steel cap is removable, which can not only prevent accidental damage to the diaphragm, but also facilitate regular cleaning

* The top sensor adopts the latest double-layer waterproof structure, which doubles the waterproof effect

Specification of Submersible Liquid Level Transmitter LFT3000

Technical parameter

LEFOO Submersible Liquid Level Transmitter LFT3000
Measurement Range0~0.5…200mH2O
Overload Pressure1.5 times full scales
Accuracy±0.5%F.S.
Stability<0.5%F.S./Year
Working Temperature-20~+85℃
Storage Temperature-40~+100℃
MediumFluids compatible with 304 and 316 stainless steel, PE, PV, Viton or NBR
LEFOO General Type Submersible Liquid Level Transducer LFT3000
Electrical PerformanceTwo-wiredThree-wiredFour-wired
Output Signal4~20mA0.5~4.5V0~5V0~10VRS485
Power Supply8~36VDC4.75~5.25VDC8~36VDC12~36VDC10~30VDC
LEFOO Digital Display Type Submersible Liquid Level Sensor LFT3000
Electrical PerformanceTwo-wiredThree-wiredFour-wired
Output Signal4~20mA0~10VRS485
Power Supply10~30VDC14~36VDC10~36VDC
Electrical ConnectionDirectly outlet
Protection GradeIP68
Pressure ConnectionThrow-in Type
Pressure FormGauge Pressure
CertificationSafety explosion-proof type E, RoHS, EU electrical safety standards CE


Dimension



Selection Guide

Code and Description

Remark

LFT3000

Submersible Liquid Level Transmitter

Model


Range

0~0.5…200mH2O

Range


A4

A4 = 4~20mA(Two-wired)

Output mode

V05

V05 = 0.5~4.5V(Three-wired)

V0

V0 = 0~5V(Three-wired )

V10

V10 = 0~10V(Three-wired )

RS

RS = RS485


M

M=Meter

Unit

CM

CM=Centimeter


0.5

0.5 = 0.5%F.S.

Accuracy


M

M =Directly outlet

Electrical connection


N

N=Without display

Display

D2D2=Explosion-proof digital display type

1.0

1.0 = 1m

Cable length

2.0

2.0 = 2m








LFT3000

0-200

A4

M

0.5

M

N

1.0


Model selection example



Features of Submersible Liquid Level Transmitter LFT3000

  • Adopt oil-filled diffusion silicon core with high precision and high overload capacity

  • Excellent corrosion and wear resistance

  • Built-in temperature compensation, support Modbus-485 communication protocol (intelligent type)

  • The bottom stainless steel cap is removable, which can not only prevent accidental damage to the diaphragm, but also facilitate regular cleaning

  • The top sensor adopts the latest double-layer waterproof structure, which doubles the waterproof effect

Applicationa of Submersible Liquid Level Transmitter LFT3000

Industrial Water Tank

Municipal water supply project

Desalination treatment

wastewater processing


To make wastewater useable again or to discharge it into the environment, it has to be clean in a multistage process of a wastewater treatment plant. There are three major cleaning steps, located between the inlet and outlet of a plant: mechanical cleaning, biological cleaning, chemical cleaning. An additional part is the treatment of the sludge, which is produced during the cleaning. In all areas, process monitoring is required to take corrective action if needed. This monitoring can be ensured by measuring the respective parameters. The level measuring can be critical for proper monitoring.


Ultrasonic technology and Radar technology and are often viewed as the "best" method of level measurement, but this is not always true in the water industry. Although they offer high performance and accuracy, in many water and wastewater applications submersible level measurement is an ideal choice because of its lower cost and anti-interference-and long-term stability.


Level measurements

Continuous level measurements and limit-level detection are needed in water and wastewater treatment plants from a process engineering, water management, and safety perspective. Level monitoring and control are key factors in optimizing operation between influent flow to the plant and treatment processes and for calculating and controlling costs.


Because no single-level technology exists that is suitable for all processes, each technology has its place depending on the process material, process conditions, and environmental conditions. Installation options are also a consideration when selecting the technology that is the best fit. In many processes, multiple-level technologies may perform equally well, leaving cost as a key consideration. Selecting the appropriate level technology for an application is critical for successful measurement, controlling the initial costs of the instruments, and eliminating costs that may be associated with maintaining a less than ideal technology.

LEFOO Application of Water Tank Sensor
