Lefoo Water Pump Controller LFPC-1

Water Pump Controller LFPC-1 is a water pump controller is a magnetic pressure sensing water controller for water systems that prevent dry run damage to the pump, which is much simpler and cost-cutting when compared to a control system composed of a pressure tank, pressure switch,  water shortage protection device, check value, and four ports. With an easy and time-saving installation. The water pump controller with complete isolation of electric part and pipe and high sealing make controller own characteristics of safety, environmental protection, long life, stable performance, less maintenance, and no noise. The water pump controller is a magnetic pressure sensing water controller for water systems

An automatic water pump pressure controller is an intelligent and economical system designed for water pressure management. It helps prevent delays, minimize vibrations, and allow for precise and accurate control of your water supply. With such a variety of functions, one of the stand-out benefits is that it’s a highly efficient piece of equipment.

An automatic pump controller essentially replaces six devices, including a pressure tank, pressure switch, check valve, pressure gauge, five-way copper, the float switch

Specification of Water Pump Controller

Rated voltage


Maximum working pressure






Maximum current


Protection level


Maximum power


Maximum operating temperature


Factory setting

1.5bar, stop when water pressure reach 3.5bar

LEFOO Specification of Water Pump Controller LFPC-1

Features of Water pump controller

With an easy and time-saving installation. The water pump controller with complete isolation of electric part and pipe and high sealing make controller own characteristics of safety, environmental protection, long life, stable performance, less maintenance, and no noise.


Setting pressure is not adjustable. Need to install on water pump with power greater than 200W. 3. Don't install any faucet between the controller and pumps. 4. The distance between the controller and the highest faucet shouldn't exceed 15M.

1. Automatic control of pump operation and shutdown.

2. Stop pumping automatically in case of water shortage.

3. Call will start automatically after a power failure.

4. Manual mandatory startup.

5. Over-pressure protection, system pressure more than 10 bars automatically stop the pump work.

6. Water shortage self-start, the time interval of self-start is 1 minute, 30 minutes, 1 hour, and then 1-hour cycle.

7. Anti-card protection, long-term non-use of the pump, 48 hours to start once.

8. Sampling pressure sensor and LED display, real-time control system pressure value.

9. Built-in two working modes, automatic mode: the controller can automatically adjust the starting pressure value according to the pressure in the pipeline, and can monitor the pressure in the pipeline in real-time. The bigger the pipeline pressure is, the smaller the starting pressure is, and the smaller the starting pressure is. It does not need to be set manually, so as to avoid the mismatch between the starting pressure and the head of the pump caused by the mismatch of the artificial setting starting pressure and the head of the pump. Obstacles occur, which can be used freely on pumps in the range of 10-98 meters lift, rated voltage, current and power. It is especially suitable for systems with mixed and superimposed pressure (such as tap water pressure or other booster pump pressure). Compared with traditional pressure controllers, it greatly reduces the occurrence of faults, thereby reducing the after-sale cost and is more intelligent. Manual setting of starting pressure value, 0.5-6.0 bar adjustable, wide range of voltage regulation, simple operation.

10. Thread interface: G1″external thread.

11. It can be configured according to the user’s requirements.

Application of Water Pump Controllers

You can use an automatic pressure controller for your domestic or household water supply, equipped with a pump to manage the pressure of your shower, sinks, sprinklers, and more. They’re useful when combined with a domestic pressure booster pump or a rainwater tank pump.

Here are some of the essential applications of an automatic pressure controller:

It controls the pump to ensure it runs at a constant flow.

When showering at home without a pressure pump or automated pressure control, you might notice the water’s inconsistent temperature or intermittent water pressure. With a device that maintains a constant water flow, you’re bound to enjoy your showers a lot more.

It automatically starts and stops the water pump whenever you open or close a tap or valve.

With an automatic pressure controller, you don’t need to turn on your pressure booster or pressure pump every time you want to take a shower or wash the dishes. By opening a tap or sink, the electronic controller will automatically start the pump.

It protects your water pump from damage with its built-in features.

By installing an automatic pressure controller, you add an extra layer of protection to your water pump. As you probably know, many factors can cause a water pump to break, such as running dry, leaks, flow switch jamming, water shortages, and more. An automatic pressure controller is designed to help prevent all of these problems and more.

How Does An Automatic Pump Controller Work?

Now that you know what an automatic pump controller is and what it can do, let’s talk about how it works.

Basically, an automatic pressure controller is a motor that will automatically switch on when water in the overhead tank (OHT) falls below the lower limit and vice versa. The circuitry behind it is straightforward, minimizing the potential for electrical issues, and it is very energy efficient too. It is powered by a 12-volt DC power supply, which consumes around as much power as charging your phone.

Without getting too technical, an automatic pressure controller relies on the water pressure to operate. Using automatic pressure control will eliminate the need for all the other components in a traditional water pressure control system, making the plumbing in your home less complicated (and less expensive too).

With less complex controls and more automation – not to mention the absence of a pressure tank, – adjusting the water pressure in your home just got a whole lot easier.

Pros and Cons of an Automatic Pump Controller

Pros of Automatic Pump Pressure Controllers:

  • Automatically stops the water pump from running dry and overheating when the water supply is running out

  • Makes your plumbing or irrigation system more efficient, meaning you’ll save water and possibly electricity as well

  • Automatically activates the electric pump, so you don’t need to stand by the water pump to turn it on or shut it down manually

  • Runs on 12V DC power, meaning it is energy efficient

  • When shut down, the auto-restart feature periodically checks if there is a water supply, so you don’t have to turn it on again manually

  • The circuitry is less complicated than using a traditional water pressure system, meaning the plumbing is less cumbersome and troubleshooting is much simpler

Cons of Automatic Pump Pressure Controllers:

  • Automation can have its disadvantages, as an automated device isn’t typically prepared for every possible scenario

  • As it is an electronic device, the circuitry required a proper and secure cover, and the device can be damaged if water gets inside

  • It Maybe challenging to install in some old houses or existing older-style plumbing networks

  • An electrician may be required to connect an automatic pressure controller if not pre-integrated with a water pump

  • Durability and longevity can vary depending on the price point – more expensive devices will inevitably deliver better results and offer more features

  • Technology can still be challenging and unfamiliar for the older generations

  • Significantly more expensive than manual pressure control valves

  • How Do You Adjust an Automatic Water Pump Pressure Controller?

  • Most automatic pump controllers for household use have set cut-in and shut-off points, so they don’t require adjusting. More advanced models can have customized pressure settings within a suitable range, which can be easily adjusted using buttons on the face of the controller.

  • Automatic Pump Control Troubleshooting

  • To prevent automatic pump control failure caused by leaks and electrical problems, consider:

  • If not already sealed, install a cover to protect the electrical components from water damage.

  • If recommended by the manufacturer, use Teflon tape when installing to prevent any leaks.

  • Make sure you consider using a barrel union between the pressure controller and the electric pump. It can be beneficial for future repairs and installation.

  • Here are some common automatic pump controller problems and what to do about them.
