Lefoo Electromagnetic Flowmeter LFLD

Name: Electromagnetic Flowmeter LFLD
Brand: LEFOO INDUSTRIAL CO.,LTD.
Rating: 4.8 (50 reviews)

Electromagnetic flowmeters have a wide range of applications, large-diameter instruments are mostly used in water supply and drainage projects; medium and small calibers are often used in high-demand or difficult-to-measure occasions, such as blast furnace tuyere cooling water control in the iron and steel industry, measurement of pulp and black liquor in the paper industry, and chemical industry. Strong corrosive liquid, ore pulp in non-ferrous metallurgy industry; small-diameter and micro-diameter are often used in places with hygiene requirements such as pharmaceutical industry, food industry, and biochemistry.

Features

* The measurement channel is a smooth straight pipe, which will not be blocked. It is suitable for measuring liquid-solid two-phase fluids containing solid particles, such as pulp, mud, sewage, etc.;

* There is no pressure loss caused by flow detection, and the energy saving effect is good;

* The measured volume flow is actually not significantly affected by changes in fluid density, viscosity, temperature, pressure and conductivity;

* Large flow range and wide caliber range;

* Corrosive fluids can be applied.

Get a Quote PDF Download

Transmitter

Pump

Specification
Features
Applications

Specification of Electromagnetic Flowmeter LFLD

Maximum velocity of flow	15m/s
Accuracy	DN15 ~ DN600	±0.5% of the indicated value (flow velocity ≥ 1m/s), ±0.2%**
		+3mm/s (flow velocity < 1m/s)
	DN700 ~ DN3000	±0.5% of the indicated value (flow velocity ≥ 0.8m/s)
		±4mm/s (flow velocity < 0.8m/s)
Fluid Electrical Conductivity	≥50μS/cm
Nominal pressure	DN10 ~ DN200	1.6MPa
	DN250 ~ DN1000	1.0MPa
	DN1200 ~ DN2000	0.6MPa
	DN2200 ~ DN3000	0.6MPa
Ambient temperature	Sensor	-25°C~ +60°C
	Converter & Integrated type	-10°C~ +60°C
Lining material & Fluid maximum temperature	Lining material	Separate type	Integrated type
	PTFE (Polytetrafluoroethylene)	120°C (special customization)	70°C
	PFA (Perfluoroalkoxy resin)	180°C (special customization)	70°C
	FEP (Fluorinated ethylene propylene)	160°C (special customization)	70°C
	Polychloroprene Rubber	80°C (special customization)	70°C
	PUR (Polyurethane)	80°C	70°C
Signal electrode form	Fixed type ( DN15 ~ DN2600 )、scraper type ( DN80 ~ DN3000 )
Signal Electrode & Ground Electrode Materials	Molybdenum-containing stainless steel, Hastelloy B, Hastelloy C, Titanium, Tantalum, latinumiridium alloy, stainless steel coated tungsten carbide
Connection flange material	Carbon steel
Grounding flange material	Stainless steel 1Cr18Ni9Ti
Inlet protection flange material	DN15 ~ DN600	Stainless steel 1Cr18Ni9Ti
	DN700 ~ DN3000	Carbon steel
IP Rate	DN15 ~ DN150separable rubber or polyurethane lined sensor		IP65, IP68 (special customization)
	DN200 ~ DN2600separable rubber or polyurethane lined sensor		IP68, 10 meters underwater
	Other sensors and all converters		IP65
Spacing (separate type)	The distance between the converter and the sensor is generally not more than 100m; if it exceeds 100m, special customization is required.

*DN700 ~ DN3000, the accuracy of special order can reach +0.3% of the indicated value (flow velocity ≥ 1m/s) or +3mm (flow velocity < 1m/s).

*Specially provide 0.2% accuracy flow meter.

Lining material	Main performance	Applications
PTFE(Polytetrafluoroethylene)	1. It is the material that has most stable chemical property among plastics: resistant to boiling hydrochloric acid, sulfuric acid, nitric acid and aqua regia, also resistant to concentrated alkali and various organic solvents, not resistant to corrosion by chlorine trifluoride, high temperature oxygen trifluoride, high flow rate liquid fluorine, liquid oxygen and ozone. 2. Poor wear resistance. 3. The ability to resist negative pressure is poor.	1. 100°C, 150°C (special customization) 2. Strong corrosive media such as concentrated acid and alkali. 3. Hygienic media.


PCR(Polychloroprene Rubber)	1. It has excellent elasticity, high breaking force and good wear resistance. 2. It is resistant to the corrosion of general low-concentration acid and alkali salt media, and not resistant to the corrosion of oxidative media.	1. 80°C, 120*C (special customization) 2. General water, sewage, weak abrasive mud, ore pulp.

PUR (Polyurethane)	1. Excellent wear resistance (equivalent to ten times that of natural rubber). 2. Acid and alkali resistance is poor. 3. It cannot be used for water mixed with organic solvents.	1. < 80°C 2. Neutral and strong abrasive slurry, coal slurry, mud, etc

Features of Electromagnetic Flowmeter LFLD

The measurement is not affected by changes in fluid density, viscosity, temperature, pressure and conductivity; .

There are no obstructing flow parts in the measuring tube, no pressure loss, and the requirements for straight pipe sections are low;

The nominal diameter of the series is DN4 ~ DN3000. There are various options for sensor lining and electrode materials;

The converter adopts a novel excitation method, with low power consumption, stable zero point and high accuracy. The flow range can reach 1500:1;

The converter can be combined with the sensor to form an integral type or a separate type;

The converter adopts 16-bit high-performance microprocessor, 2x16LCD display, convenient parameter setting and reliable programming;

The flowmeter is a two-way measurement system with three built-in totalizers: forward total, reverse total and difference total; it can display forward and reverse flow, and has a variety of outputs: current, pulse, digital communication , HART, RS485 protocol;

The converter adopts surface mount technology (SMT), with self-check and self-diagnosis functions;

Rubber and urethane lined sensor for intrinsic immersion structure;

Explosion-proof instruments can be used in corresponding explosion-proof places;

Electromagnetic flowmeter is used to measure the volume flow of conductive liquid and slurry in closed pipelines. It is suitable for chemical, electric power, metallurgy, petroleum, water supply and drainage, papermaking, medicine, food and other departments.

LEFOO Company

LEFOO Industrial Co., Ltd has 6 laboratories with advanced and complete equipment to develop and improve the accuracy of existing products in various ranges and various temperature conditions. It also has a semi-automatic dust-free production center for the manufacture of pressure transmitters. Please contact our sales team to get the best pressure transmitter price.

Applications of Electromagnetic Flowmeter LFLD

Selection Help Guide

Selection principles.

The fluid to be tested must be a conductive liquid or slurry with a conductivity of not less than 50μS/cm, and the fluid to be tested should not contain many ferromagnetic substances or bubbles.

The appropriate pressure level, lining material, electrode material and instrument structure should be selected according to the characteristics of the fluid to be measured.

Path selection

1. Because the electromagnetic flowmeter has a high range of 1500:1, the diameter of the instrument is usually the same as that of the process pipeline.

2. If the measured medium contains solid particles, the recommended flow rate range is 1 - 3m/s. If the actual flow rate is too large and it is inconvenient to change, the diameter of the optional instrument is larger than that of the process pipeline.

To reduce the flow rate of the fluid in the measuring pipe section of the flowmeter properly, reduce the wear of the particles on the electrode and the lining.

3. If there may be sediment in the process pipeline, the recommended flow rate is 2-5m/s. If the actual flow rate is too small and it is inconvenient to change the process pipeline, the optional instrument with a small diameter

According to the diameter of the process pipeline, the fluid flow rate of the flowmeter can be appropriately increased to avoid the influence of sediment on the accuracy of the meter.

4. When the flow rate is too small and high-precision measurement is required, a sensor smaller than the diameter of the process pipeline can be selected to increase the flow rate and ensure higher accuracy.

In the above 2, 3, and 4 cases, reducers must be installed upstream and downstream of the flowmeter. The central cone angle of the reducer should not be greater than 15°, and there should be at least a straight pipe section upstream of the reducer that is five times the diameter of the process pipe.
